Q-Tech適用于極端溫度和井下應用的高溫晶體振蕩器

發布時間：2021-04-13 16:58:21 瀏覽：3439

Q-Tech Corporation為地下應用領域提供最先進性的高溫混合晶體振蕩器。產品包括規范數字時鐘、實時時鐘和音叉時鐘頻率。

Q-Tech振蕩器設計在-55°C至+200°C的范圍內(最大范圍為+250°C)。Q-Tech高溫振蕩器是為極端環境設計的，例如井下鉆井、高溫航空電子設備、噴氣發動機傳感器、地?zé)崮茉春凸I(yè)應用領域。除去能夠承擔高溫環境之外，Q-Tech振蕩器還能抵御高沖擊和振動。

Q-Tech產品都滿足高可靠性設計、質量、按時交貨和一流的顧客服務的高標準化。Q-Tech專注于為客戶提供先進的頻率控制解決方案。

深圳市立維創展科技有限公司授權代理銷售Q-TECH產品，備用部分現貨，歡迎與業界同行合作。

詳情了解Q-Tech請點擊：/brand/60.html

或聯系我們的銷售工程師：0755-83642657 QQ: 2295048674


Package	Dimensions (mm)	Market	Device Type	Logic Type	Supply Voltage	Stability	Phase Noise Floor
QTCH230	2.50 x 3.20 x 1.15	High Temp	XO	CMOS	1.8 to 3.3Vdc	±150ppm to ±250ppm	Contact Q-Tech
QTCH230 (32K768)	2.50 x 3.20 x 1.15	High Temp	XO	CMOS	2.5 to 3.3Vdc	±150ppm to ±250ppm	Contact Q-Tech
QTCH350	3.20 x 5.00 x 1.20	High Temp	XO	CMOS	1.8 to 3.3Vdc	±150ppm to ±250ppm	Contact Q-Tech
QTCH350 (32K768)	3.20 x 5.00 x 1.20	High Temp	XO	CMOS	2.5 to 3.3Vdc	±150ppm to ±250ppm	Contact Q-Tech
QTCH570	5.00 x 7.00 x 1.40	High Temp	XO	CMOS	1.8 to 3.3Vdc	±150ppm to ±250ppm	Contact Q-Tech
QTCH570 (32K768)	5.00 x 7.00 x 1.40	High Temp	XO	CMOS	2.5 to 3.3Vdc	±150ppm to ±250ppm	Contact Q-Tech
QT1123L, QS1123L, QG1123L	22.35 x 12.83 x 5.08	High Temp	XO - RTC	CMOS	-5.2 to -4.5Vdc & 1.8 to 15Vdc	±40ppm to ±250ppm	Contact Q-Tech
QT2024	12.8 x 12.8 x 5.08	High Temp	XO - RTC	CMOS	3.3Vdc	±40ppm to ±250ppm	Contact Q-Tech
QT380, QT381, QT382, QT383, QT384, QT385, QT386, QT387, QS380, QS381, QS382, QS383, QS384, QS385, QS386, QS387	5.0 x 7.0 x 2.54	High Temp	XO - RTC	CMOS	2.5 to 3.3Vdc	±150ppm to ±250ppm	Contact Q-Tech
QT581, QT582, QT583, QT584, QT588, QT589, QT590, QT592, QS581, QS582, QS583, QS584, QS588, QS589, QS590, QS592	5.00 x 7.00 x 2.00	High Temp	XO - RTC	CMOS	2.5 to 3.3Vdc	±40ppm to ±250ppm	Contact Q-Tech
QT81, QS81	5.00 x 7.00 x 2.00	High Temp	5x7 w/ 4pt Mount	CMOS, LVHCMOS, TTL	1.8 to 5Vdc	±175ppm to ±450ppm	Contact Q-Tech
QT86	5.00 x 7.00 x 2.00	High Temp	5x7 w/ 4pt Mount	CMOS, LVHCMOS, TTL	1.8 to 5Vdc	±175ppm to ±450ppm	Contact Q-Tech
